| Operating system |
Windows 10 Pro 64 – HP recommends Windows 10 Pro Windows 10 Pro 64 (National Academic only) Windows 10 Home 64 Windows 10 Home Single Language 64 FreeDOS 2.0 |
| Processor Family |
Intel Celeron processor (G4900 is Windows 10 only); 8th Generation Intel Core i7 processor (i7-8700); 8th Generation Intel Core i7 + processor (Core i7 and Intel Optane memory); 8th Generation Intel Core i5 + processor (Core i5 and Intel Optane memory); 8th Generation Intel Core i5 processor (i5-8500, i5-8600); 8th Generation Intel Core i3 processor (i3-8100, i3-8300); Intel Pentium processor (G5400, G5500, G5600 are Windows 10 only) |
| Processors |
Intel Core i3-8100 with Intel UHD Graphics 630 (3.6 GHz, 6 MB cache, 4 cores); Intel Celeron G4900 with Intel UHD Graphics 610 (3.1 GHz, 2 MB cache, 2 cores); Intel Pentium Gold G5400 with Intel UHD Graphics 610 (3.7 GHz, 4 MB cache, 2 cores); Intel Core i3-8300 with Intel UHD Graphics 630 (3.7 GHz, 8 MB cache, 4 cores); Intel Pentium Gold G5500 with Intel UHD Graphics 630 (3.8 GHz, 4 MB cache, 2 cores); Intel Core i7-8700 vPro processor with Intel UHD Graphics 630 (3.2 GHz base frequency, up to 4.6 GHz with Intel Turbo Boost Technology, 12 MB cache, 6 cores); Intel Core i7+ 8700 vPro processor (Core i7 and 16 GB Intel Optane memory) with Intel UHD Graphics 630 (3.2 GHz base frequency, up to 4.6 GHz with Intel Turbo Boost Technology, 12 MB cache, 6 cores); Intel Core i5-8600 vPro processor with Intel UHD Graphics 630 (3.1 GHz base frequency, up to 4.3 GHz with Intel Turbo Boost Technology, 9 MB cache, 6 cores); Intel Core i5+ 8600 vPro processor (Core i5 and 16 GB Intel Optane memory) with Intel UHD Graphics 630 (3.1 GHz base frequency, up to 4.3 GHz with Intel Turbo Boost Technology, 9 MB cache, 6 cores); Intel Core i5-8500 vPro processor with Intel UHD Graphics 630 (3 GHz base frequency, up to 4.1 GHz with Intel Turbo Boost Technology, 9 MB cache, 6 cores); Intel Core i5+ 8500 vPro processor (Core i5 and 16 GB Intel Optane memory) with Intel UHD Graphics 630 (3 GHz base frequency, up to 4.1 GHz with Intel Turbo Boost Technology, 9 MB cache, 6 cores) |
| Chipset |
Intel Q370 |
| Form factor |
All-in-one |
| Maximum Memory |
32 GB DDR4-2666 SDRAM Transfer rates up to 2666 MT/s |
| Memory slots |
2 SODIMM |
| Internal Storage |
500 GB up to 2 TB SATA HDD up to 500 GB 7200 rpm SATA SED Opal 2 HDD up to 500 GB 7200 rpm SATA SED FIPS HDD 256 GB up to 512 GB SATA SSD 256 GB up to 512 GB SATA SED Opal 2 TLC SSD 256 GB up to 512 GB SATA SED FIPS SSD 128 GB up to 512 GB PCIe NVMe M.2 SSD 256 GB up to 512 GB PCIe NVMe SED Opal 2 TLC M.2 SSD |
| Additional storage |
1 SD media card reader |
| Optical drive |
HP 9.5 mm Slim DVD-Writer; HP 9.5 mm Slim DVD-ROM; HP 9.5 mm Slim Blu-ray writer |
| Display |
21.5" diagonal FHD IPS widescreen LCD anti-glare WLED-backlit touch screen (1920 x 1080) |
| Available Graphics |
Integrated: Intel UHD Graphics 630; Intel UHD Graphics 610 |
| Audio |
Conexant CX3601 codec, 2 W internal stereo speaker, headset and headphone side port (3.5 mm), multi-streaming capable |
| Expansion Slots |
1 M.2 2230; 1 M.2 2230/2280 (1 M.2 2230 slot for WLAN and 1 M.2 2230/2280 slot for storage.) |
| Ports and Connectors |
Side: 1 headphone/microphone combo; 2 USB 3.1 Gen 1; 1 USB 2.0 Type-C Rear: 1 DisplayPort 1.2; 1 power connector; 1 RJ-45; 2 USB 3.1 Gen 1 Optional: 1 DisplayPort 1.2; 1 serial; 1 HDMI 2.0 |
| Drive Bays |
One 2.5" HDD |
| Camera |
1 MP HD webcam with integrated dual array digital microphone, maximum resolution of 1280 x 720; 2 MP FHD webcam with integrated dual array digital microphone, maximum resolution of 1920 x 1080; 2 MP FHD IR webcam with integrated dual array digital microphone, maximum resolution 1920 x 1080 |
| Input Devices |
HP USB and PS/2 Washable Keyboard; HP USB Conferencing Keyboard; HP USB Healthcare Edition Keyboard and Mouse Combo; HP USB Value Keyboard and Mouse Combo; HP USB Wired Keyboard; HP Wireless Business Slim Keyboard and Mouse Combo; HP Wireless Premium Keyboard and Mouse Combo; USB Business Slim Standalone Wired Keyboard; HP USB Collaboration Wired Keyboard; HP Wireless Collaboration Keyboard; HP USB Business Slim Smart Card (CCID) Keyboard; HP USB 1000 dpi Laser Mouse; HP USB Mouse; HP USB Optical Mouse; HP USB Premium Mouse |
| Communications |
LAN: Intel I219LM GbE; WLAN: Intel Dual Band Wireless-AC 9560 802.11ac (2x2) and Bluetooth 5 M.2 PCIe, non-vPro; Intel Dual Band Wireless-AC 9560 802.11ac (2x2) and Bluetooth 5 M.2 PCIe, vPro |
| Available Software |
Absolute Persistence module; HP Device Access Manager; HP Hotkey Support; HP Noise Cancellation Software; HP Recovery Manager; HP Secure Erase; HP Support Assistant; HP Sure Click; Native Miracast Support; Skype for Business Certified; HP Wireless Wakeup; Buy Office (sold separately); Windows Defender; HP JumpStarts |
| Security management |
DriveLock; Hood sensor; HP BIOSphere; HP Credential Manager; HP Password Manager; HP Power On Authentication; HP Spare Key; Intel Identity Protection Technology (Intel IPT); Intrusion detector; Power-on password (via BIOS); Removable media write/boot control; SATA port disablement (via BIOS); Setup password (via BIOS); USB enable/disable (via BIOS); HP Sure Start Gen 4; Master Boot Record Security; HP Client Security Suite Gen 4; Pre-boot Authentication; Serial enable/disable (via BIOS); Trusted Platform Module TPM 2.0 Embedded Security Chip shipped with Windows 10 (Common Criteria EAL4+ Certified)(FIPS 140-2 Level 2 Certified); Support for table lock; Support for chassis padlocks devices |
| Management features |
HP BIOS Config Utility (download); HP Client Catalog (download); HP Driver Packs (download); HP System Software Manager (download); Update BIOS via Cloud or Network (BIOS feature); Ivanti Management Suite; HP Management Integration Kit for Microsoft System Center Configuration Management Gen 2 |
| Power |
120 W external power adapter, up to 89% efficiency, active PFC |
| Dimensions (W X D X H) |
19.26 x 8.21 x 14.32 in 48.91 x 20.85 x 36.37 cm (With adjustable height stand.) |
| Weight |
12.74 lb 5.78 kg (Lowest weight configuration with adjustable height stand. Weight will vary by configuration.) |
| Energy Efficiency Compliance |
ENERGY STAR certified; EPEAT Gold |
| Environmental |
Operating temperature: 10 to 35°C; Operating humidity: 10 to 90% RH |
| Environmental specifications |
Low halogen |
| Warranty |
3 year (3-3-3) limited warranty and service offering includes 3 years of parts, labor and on-site repair. Includes free 24/7 telephone support. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
